Note: Offsets can be negative or positive.
Time Signature
Number of Bars
Snap Grid
The Information pane shows all currently defined Time Signatures. The Time Signature , Number of Bars and
Snap Grid fields reflect the values for the highlighted (selected) Bars & Beats section.
Tempo
BPM
Frames & Perfs
Smoothing
Start
End
Time Signature and Bars
The bottom left panel displays a list of blocks of bars in the order they appear in the 'song' . The following settings
apply to the currently selected entry in the list.
Time Signature
Number of Bars
Snap Grid
Add Bars
Click to add a new block of bars to the list above.
Remove Bars
Deletes the selected entry from the list above.
Bars & Beats Ruler Toolbar
From within the Bars and Beats Control Toolbar, the following can be accomplished:
M IN
M Out
R In
R Out
Start
Note: in the Bars & Beats Settings dialog, the Offset field will reflect the value entered in Start.
However, pressing the Store button, will default the offset value to the difference between 00.00.00.00 and the
Metro
Volume
Set the Time Signature by selecting from the drop-down lists.
Type the Number of Bars required or choose Infinite from the drop-down list.
Select the required resolution from the drop-down list
Choose a tempo from the common values in the drop-down list, increment or dec-
rement in 1bpm steps with the up and down buttons or type a value in the box.
Another way of expressing BPM. The value entered here will be reflected in the
BPM field.
Smoothing is a ramp, used mainly when a tempo changes at some point in a proj-
ect. For example you could smooth up gradually the passing from a 120 bpm to a
80 bpm tempo. Values can be selected between Note and 1/64 . (or OFF )
Enter a Start value
Enter an End value or choose Infinite from the drop-down list.
Use the combo boxes to set the Time Signature
Type a value or choose Infinite from the combo box dropdown list.
Combo box offers a choice of Off or values between Note and 1/64 Note .
Centers the Timeline on the In Marker.
Centers the Timeline on the Out marker.
Centers the Timeline on the beginning of the current Selection or Range .
Centers the Timeline on the end of the current Selection or Range .
The Start register enables an Offset to be entered for the first Bar, counting from
00.00.00.00 , independent of the Playhead Cursor position.
present Playhead Cursor position.
Clicking on Metro opens the Metronome Settings dialog. Clicking on the label to
the right toggles through On , Pre-Roll only and Off .
Below Metro the volume slider sets the metronome click level.
Productivity : Bars & Beats
Bars & Beats Ruler Toolbar
