Print Masters Track Banks
The selected banks of 8 tracks are armed for recording when any OTHER track is armed. This is primarily useful
when recording a Print Master or Masters at the same time as stems. E.g. if you are recording Dialogue, Music and
Effects stems it is common practice to update an element on one stem only. However, the final mix Print Master,
which is the sum of all the stems must be updated at the same time. Print Masters Track banks allow the user to
forget about arming the Print Master Tracks and concentrate on the stems.
Filter Arming of Print Masters Tracks
When ticked, arming a Print Master Track will not arm the other Print Master Tracks.
No Tallies for Print Masters Tracks
When ticked, record tally commands are filtered out for the Print Masters Tracks.
Port
• Serial (RS422) Select this option if the connection uses conventional 9-pin cabling
• Pipe (Ethernet) Select this option if connecting to Pyramix or VCube machine(s) using Sony P2 over IP.
Configure
Clicking the Configure button opens the respective configuration dialog.
COMM422 Configuration:
Serial Port
Shows the current Serial Port selected from the drop-down list. If not already highlighted, select the desired serial
COM port. Standard choices are either COM1 or COM2.
Click OK to confirm the choice. This automatically sets the selected COM port with the proper parameters of the
Sony 9-pin communication protocol.
Remote Identification
• Port Name* The entry here must match the Controller Port Name on the other Computer
COMM422 Configuration dialog
Remote Identification dialog
