HORUS Preamp Remote Controls - Detail
The field at the top shows the Preamp Gain set with the knob. Adjustable between 0dB and 60dB when the pre-
amp is switched to Mic or Line . May also be clicked to enter a fader gain value directly.
Pad
HPF
Phase
48V Phantom
Mic/Line
Notes
When the last mouse click was somewhere in the Preamp Control section of the mixer strip the gain can be
adjusted from the keyboard up and down arrows in 0.5dB increments.
Control of Individual Channels in Stereo Strips
Clicking the + button next to the Mic or Line indicator in a stereo channel opens the Preamp Channels Control
panel.
This panel enables the same parameters found in a mono Strip to be set per channel. If a gain offset is applied this
is indicated on the single knob in the strip by a second orange dot. The left and right arrows either side of the
channel numbers step left and right across the mixer. Alternatively channels may be selected from the drop down
list.
VCA Group Strip
When changes are made in a VCA Group Strip all controls of all group members will update to match. However, if
the Gains of each strip are different the gain will not go below 0dB for the lowest strip's PreAmp Gain value when
using the VCAGroup control. This 0dB barrier can be broken by using Ctrl while changing the gain. Of course this
means that any strips affected will lose their gain relationship with the other strips in the group.
HORUS Preamp Remote Controls
Lights purple when the Pad is active.
Lights green when the 80Hz Filter is active.
Lights Blue when Phase is reversed.
Lights red when the 48V Phantom Power is switched on.
Displays the current preamp mode. Clicking on the box pops-up a list with the
choice of Mic or Line.
Preamp Channels Control panel
Mixer : HORUS Preamp Remote Controls 10 - 237
