Note: The field may be left blank if only one port is used.

Transport Commands Filtering

Filter Transport Commands Except Edit On/Off When ticked all transport commands apart from Edit On

or Edit Off are filtered out.

Always Process Stop Some controllers send a Chase Off command for Stop. If you need this command

when filtering Transport Commands, checking the box will allow it through.

Play Command Resets Loop Mode (I.e. the transport Loop)

Note: These filter settings are mainly relevant where multiple controllers are in use. E.g. where a

Mixing console controls monitoring and recording.

Edit On/Off Frame Alignment and Delay

Edit On and Edit Off boxes enable delays (in ms) to be entered.

Note: 0 = Immediate Punch, 1 = Align to next Frame boundary, 2 or more = Align to the given

following Frame boundary.

Edit Preset (Track Arming) Mapping

The Map Track # combo box allows you to select a Track between 1 and 96 to be mapped to a choice made in the

second combo box from:

or any Track between 1 and 96

This function is useful if more than one Pyramix is to be controlled by the same controller. E.g. with two machines

set up to record 32 Tracks each, Pyramix one is mapped 1 - 1 to 32 - 32 and Pyramix two is mapped 1 - 33 to 32 -

Settings : Remote Control
