Dynamic Automation Levels - Merging Pyramix User Manual

Please see also: Filter Automation Tracks to Snapshot Dialog on page 381
Designated Bus Selector for Fader Alignment

Dynamic Automation Levels

There are two "levels" of automation in the mixing console.
Level 1
The modes as defined per Strip in the section atthe bottom of the mixer:
Clicking on the upper button pops-up the list of available Strip Automation Modes:
• Touch
• Latch
• Trim
• Touch
• Trim Latch
• Record
• Read
• Isolate
The Snapshot Range button opens the Filter Automation Tracks to Snapshot Range dia-
log. When OK is pressed automation snapshot key frames of all enabled controls are inserted
at the Mark In and Mark Out cursor positions. In effect, this sets all enabled controls to the
current state throughout the range defined by the marks.
The box shows which bus the automation is aligned with when auto-
matic delay compensation is active. The drop-down list shows all available buses plus the
option of none.
Control Strip Automation Mode pop-up
Automation : Dynamic Automation Levels
Control strips Automation buttons
15 - 365
