Foldback

Continuing the foregoing Talkback example it is also possible to add foldback to the Talkback outputs. To add
Foldback to the Vocal Booth Talkback outputs click on the black box to the right of the Vocal Booth label to drop-
down a list of available Foldback sources:
Monitor Talkback page : Select Foldback Source
Select the required Foldback Studio Monitor Source .
Note: You can add a bus in the mixer specifically to produce a mix for Foldback.
The buttons on the left of the Vocal Booth label etc. toggles the foldback on and off per destination:
Monitor Talkback page : Foldback to Vocal Booth Active
Here, the Vocal Booth is fed with ST1 (Main) bus output. The vocals are recorded clean on M1 (Mono Mix) and,
as can be seen above, the Mixer Room monitors are being fed with the sum of these buses.
Monitor : Talkback 11 - 285
