2. On the PGROUPS Setup page, enter values for the parameters indicated in
Web Page Item
Bypass DTMF
#
Address
Port
Name
TTL
Lineout
3. After changing the parameters, click Save Settings.

2.4.10 Operating the Paging Server

• When you call to make a page, the V3 Paging Server generates a tone over the phone.
• When you hear this tone, enter the two-digit code for the zone that you want to page.
• The V3 Paging Server establishes a connection to a zone.
• The V3 Paging Server generates another tone to the phone.
• When you hear this tone, you can begin speaking.
Note
CyberData Corporation
Table 2-11. PGROUPS Setup Parameters
For page-all, you simply configure all speakers with a particular multicast address and port
number combination, which represents one of the 100 zones that the paging server will
support initially. Each speaker can still be part of 100 other paging zones in addition to the
one page-all zone.
930427B
Description
When selected, bypassing the DTMF will result in all calls
being relayed to PGROUP 0.
Shows the paging group number.
Enter the IP address of the PGROUP.
Enter the port number of the PGROUP.
Enter a name for the PGROUP.
The TTL field allows you to adjust the TTL. TTL is "time to
live" and it describes how many networks (routers) a packet
will go through before it is discarded. For more information,
see Appendix C, "How to Use the Multicast
The Lineout field determines whether or not the V3 Paging
Server will play audio out of the line-out port in addition to
forwarding it to the Pgroup.
Setting Up the V3 Paging Server
Configuring the V3 Paging Server
Table 2-11.
Extensions.
