Peavey MMA 8150T Amplifier to V3 Paging Server Connections
The IP Endpoint Company
Peavey MMA 8150T Amplifier
V3 Paging Server Connections
+ -
+
-
PGM IN
or
Notes
CyberData V3 Paging Server's RCA line level output can connect to either an AUX 2 module
or a TPM-S2 Module.
This page shows the possible connections to an AUX 2 module.
Connect the V3 Paging Server's Line Out to one of the RCA phono input jacks.
930990A
Advertisement
Table of Contents
Related Manuals for CyberData V3 Paging Server
Summary of Contents for CyberData V3 Paging Server
- Page 1 V3 Paging Server Connections PGM IN Notes CyberData V3 Paging Server's RCA line level output can connect to either an AUX 2 module or a TPM-S2 Module. This page shows the possible connections to an AUX 2 module. Connect the V3 Paging Server's Line Out to one of the RCA phono input jacks.
- Page 2 This page shows possible connections to a TPM-S2 module Relay Contact - Normally Open Connect the V3 Paging Server's Page Port output terminal pins to the INPUT a.The 600-Ohm audio output of the page port is on the TPM-S2 module.
