2.2.2 Connecting the Paging Amplifier

2.2.2.1 Using the Amplified Outputs
Figure 2-4
amplified outputs in low and high power mode.
Low Power Mode
Operations Guide
and Figure 2-5 illustrates how to connect the VoIP V2 Paging Amplifier and use the
Figure 2-4. Using the Amplified Outputs—Low Power Mode
Note: You can use an 802.3af
compliance switch instead of an
802.3af power injector and hub.
802.3af PoE Injector (low power mode)
Non-PoE Ethernet Switch
Use 16 gauge wire coming out of screw terminals.
Note: The maximum wire length from the amplifier
to the speaker should not be more than 25 feet.
Cat 5 Ethernet Cable
+
930363B
Installing the VoIP V2 Paging Amplifier
Paging Amplifier Setup
Standard 1 Speaker Configuration
(802.3af mode)
8 Ohms
-
16 gauge wire
+
