Replacing the Fan Tray

•
•
•
•
•

Required Tools

You might need a flat-blade or number 2 Phillips-head screwdriver to loosen or tighten the captive installation
screws on the fan tray.

Removing the Fan Tray

The fan tray is designed to be removed and replaced while the system is operating without presenting an
electrical hazard or damage to the system.
Note You have 120 seconds to remove and insert of the fan-tray, under specified ambient operating temperatures.
The fans might still be turning when you remove the fan from the chassis. Keep fingers, screwdrivers,
Warning
and other objects away from the openings in the fan's housing. Statement 263
Procedure
Step 1 Locate the fan tray as shown in the figure.
OL-30827-02
Required Tools, page 73
Removing the Fan Tray, page 73
Installing the Fan Tray, page 75
Checking the Installation, page 76
Finding the Fan Serial Number, page 77
