Installing the USB Drivers
•
•

Installing the Cisco Microsoft Windows USB Device Driver

A USB device driver must be installed the first time a Microsoft Windows-based PC is connected to the USB
console port on the switch.
•
•
•

Installing the Cisco Microsoft Windows XP USB Driver

Procedure
Step 1 Obtain the Cisco USB console driver file from the Cisco.com web site and unzip it.
Note
Step 2
If using 32-bit Windows XP, double-click the setup.exe file in the Windows_32 folder. If using 64-bit Windows
XP, double-click the setup(x64).exe file in the Windows_64 folder.
Step 3 The Cisco Virtual Com InstallShield Wizard begins.
Step 4
The Ready to Install the Program window appears. Click Install.
Step 5 The InstallShield Wizard Completed window appears. Click Finish.
Step 6 Connect the USB cable to the PC and the switch console port. The USB console port LED turns green, and
the Found New Hardware Wizard appears. Follow the instructions to complete the driver installation.
OL-30827-02
Installing the Cisco Microsoft Windows USB Device Driver, page 109
Uninstalling the Cisco Microsoft Windows USB Driver, page 110
Installing the Cisco Microsoft Windows XP USB Driver
Installing the Cisco Microsoft Windows 2000 USB Driver
Installing the Cisco Microsoft Windows Vista and Windows 7 USB Driver
You can download the driver file from the Cisco.com site for downloading the switch software.
E
A P P E N D I X
Catalyst 6880-X Switch Hardware Installation Guide
109
