Product Overview
Management Port LED, on page 11
Fan Tray LEDs, on page 12
AC-Input Power Supply LEDs, on page 13
DC-Input Power Supply LEDs, on page 14
System Status LED
The system status LED indicates the status of the system.
Table 2: System Status LED Indicator
Color/State
Off
Green
Amber
Red
Related Topics
LED Indicators, on page 8
Status LED on the Modular Port Card
The Status LED indicates the status of the modular port card.
Table 3: Status LED Indicator
Color/State
Off
Green
Amber
Red
System ID LED
The System ID (blue beacon) LED can be provisioned by the operator to indicate that the switch needs
attention.
OL-30827-02
Description
System is not operational.
System operating normally without alarms.
System has triggered a minor environmental alarm.
System has triggered a major environmental alarm.
Description
Port card is not operational.
Port card is operating normally without alarms.
Port card has triggered a minor environmental alarm.
Port card has triggered a major environmental alarm, or the system is powering
up.
Catalyst 6880-X Switch Hardware Installation Guide
LED Indicators
9
