Rack-Mounting the Chassis
Figure 17: Installing the Cable Mount Guides
1
What to Do Next
After installing the chassis in its location, complete the installation process by following these procedures:
• Connecting the chassis to system ground. See
• Installing and connecting the power supplies to source power. For information on how to install and
cable power supplies, see the
• Connecting to the switch console port. See
• Connecting to the uplink ports.
• Powering-up the chassis and verifying the installation. See
page

Catalyst 6880-X Switch Hardware Installation Guide

44
10-32 or 12-24 screws
Installing Power Supplies, on page
51.
Establishing the System Ground, on page
55.
Connecting the Switch Console Port, on page
Verifying Switch Chassis Installation, on
Installing the Switch
45.
47.
OL-30827-02
