Power Supply Slots

Figure 4: Modular Port Card (C6880-X-LE-16P10G and C6880-X-16P10G)
1
2
3
For a list of supported SFP and SFP+ modules, see the switch data
products/collateral/switches/catalyst-6880-x-switch/data_sheet_c78-728228.html
Power Supply Slots
The chassis has two slots that accept either two 3000 W AC-input or two 3000 W DC-input power supplies,
or one of each. The chassis is delivered with power supplies already installed in the power supply slots. If
only one power supply is ordered, then a blank cover is installed in the empty power supply slot, which must
remain installed if a power supply is not installed.

Catalyst 6880-X Switch Hardware Installation Guide

6
16 SFP+ or 100BASE-FX SFP ports
Status LED
Port LEDs
4 Extraction handle
5 Port card
6 ID (blue beacon LED)
sheet:http://www.cisco.com/c/en/us/
.
Product Overview
OL-30827-02
