Step 3 Attach the alligator clip directly over the head of the system ground lug screw or to the system ground lug
barrel.
Figure 11: Attaching the ESD Wrist Strap to the System Ground Lug Screw

Power Requirements

When preparing your site for the switch installation, follow these requirements:
• When installing two power supplies, connect each power supply to a separate input power source. If
• To prevent a loss of input power, be sure that the total maximum load on each source circuit is within
• You might decide to use an uninterruptible power supply (UPS) to protect against power failures at your
• The AC-input power supply has a detachable power cord that allows you to connect each power supply
• You can connect the DC-input power supply to the power source with heavy-gauge wiring connected
• If you are using a 200/240 VAC power source in North America, the circuit must be protected by a
• The source AC outlet must be within 6 feet (1.8 meters) of the system and should be easily accessible.
OL-30827-02
you fail to do this, your system might be susceptible to total power failure due to a fault in the external
wiring or a tripped circuit breaker.
the current ratings of the wiring and breakers.
site. Be aware when selecting a UPS that some UPS models that use ferroresonant technology can become
unstable when operating with the Catalyst 6880-X switch power supplies which use power factor
correction (PFC). This can cause the output voltage waveform to the switch to become distorted resulting
in an undervoltage situation in the system.
to the site power source.
to a terminal block. The wire gauge size is determined by local electrical codes and restrictions.
two-pole circuit breaker.
