Preparing for Installation
• The circuit breaker is considered to be the disconnect device and should be easily accessible.
• The circuit must be protected by a dedicated two-pole circuit breaker. The circuit breaker should be
• For proper DC-input redundant power configurations on systems with multiple-input DC-input power
• For DC-input power supplies with multiple inputs, each DC input must be protected by a dedicated

Cabling Requirements

When running power and data cables together in overhead cable trays or subfloor cable trays, be aware of the
following caution:
We strongly recommend that power cabling runs and other potential noise sources be located as far away
Caution
as practical from LAN cabling that terminates on Cisco equipment. In situations where this type of long
parallel cable runs exist and cannot be separated by at least 3.3 feet (1 meter), we recommend that you
shield these potential noise sources. To avoid interference, the source should be shielded by housing it in
a grounded metallic conduit.
Also be aware of the following caution concerning the use of Category 5e and Category 6 Ethernet cables:
Category 5e, Category 6, and Category 6a cables can store large levels of static electricity because of the
Caution
dielectric properties of the materials used in their construction. Always ground the cables (especially in
new cable runs) to a suitable and safe earth ground before connecting them to the module.

Site Preparation Checklist

The following table lists the site-planning activities that you should perform prior to installing the switch.
Completing each activity helps ensure a successful switch installation.
OL-30827-02
sized according to the power supply input rating and local or national code requirements.
supplies, all pairs of source DC cables for one DC-input power supply must come from the same battery
system (A feed); all pairs of source DC cables for the second DC-input power supply must come from
a different battery system (B feed).
circuit breaker or a fuse. The circuit breaker or the fuse must be sized according to the power supply
input rating and local or national electrical codes.

Catalyst 6880-X Switch Hardware Installation Guide

Cabling Requirements
29
