Front routing:
a. Unwind the power cord and route it under the upright.
b. Slide the grommet into the front exit hole with the curved end first. See Figure 11.
Grommet
Figure 11
Back routing:
a. Using a Phillips head screwdriver, remove the left end cap.
b. Remove the grommet from the back exit hole and slide it into the
front exit hole.
c. Slide the grommet on the power cord into the back exit hole with the curved
end first.
d. Using a Phillips head screwdriver secure the left end cap. See Figure 12.
Grommet
Slot at
Front of
Treadmill
Figure 12
B. Wind the excess power cord onto the arms. See Figure 12.
C. Place the left side panel into position slightly under the end cap and use your hand to
push all along the bottom edge of the side panel to snap it in place.
Setup
&
Assembly
Page 5-8
Cybex TROTTER Elite Treadmill Owner's & Service Manual
Arms
Wire Ties
Arms
End
Cap
Screw
