5. Attach the console back.
A. While being sure not to pinch any cables, secure the console back to the console with
the five Phillips head screws.
6. Test the new display overlay.
A. Turn the main power switch to the on (I) position.
B. Plug the treadmill into the power outlet.
C. Try each key to be sure that it functions properly.

Parts List

ITEM PART NO.
NO.
1 AF-16240
2 HS-16929
3 HS-16950
4 HS-16939
5 PL-16256
6 PL-16465
7 PL-16464
8 HW-13799
9 AX-16721
10 HX-16706
11 HX-16707
12 HS-15682
13 AX-16871
14 AX-16725
15 AF-16325
16 AX-16722
17 DE-16705
18 HS-16875
19 EH-10291
20 EH-00986
21 PL-16737
21 AW-17273
21 AW-17272
21 AW-17274
22 PL-16738
23 DE-16992
24 Removed
25 PC-16496
26 PC-16497
27 HX-15678
28 EH-16809
29 HX-14416
30 DE-16928
31 HW-00590
32 HX-13771
33 HX-16510
34 FS-16511
35 HS-16509
36 HS-15480
37 HB-16367
38 HW-10028
39 HX-11049
40 AX-16723
40 AF-17591
Service
Page 7-38
Cybex TROTTER Elite Treadmill Owner's & Service Manual
DESCRIPTION
Frame, Weldment
Screw, 3-8-16 x 5-8Lg H x HD whiz-lock GR5
Screw, 5-16-18 x 7-8Lg H x Soc BtnHD w/patch, B-Zn
Screw, SEM 10-32 x .75 Pnhd Ext blk Zn
Cover, Motor
Cover, Upright Outer, Right
Cover, Upright Outer, Left
Washer, Flat
Deck Stiffener Assy
Tape Strip, 1.88 x 41.0 x .010thk
Tape Strip, 1.32 x 4.30 x .010thk
Screw, 5/16-18 x .50 FLHD Phil undercut ZN
Side Extrusion Assy, Elite, Right
Side Extrusion Assy, Elite, Left
Upright Weldment, (Choose a Standard or or Custom Color)
Top Platform Assy, (Choose a Standard or or Custom Color)
Decal, Safety-walk
Screw, SEM ext 1-4-20 x 1-2 PNHD Phil
Anchor, Cable Tie
Cable Tie, (without anchor)
Plug, Power Cord Grommet
Power Cord 220V 60Hz (NOT SHOWN)
Power Cord 230V 50Hz (NOT SHOWN)
Power Cord 115V 60Hz (NOT SHOWN)
Grommet,.45 ID, Power Cord
Decal, ETL UL-1647 Only
End Cap, Left, (Choose a Standard or or Custom Color)
End Cap, Right, (Choose a Standard or or Custom Color)
Bushing Deck 5/16-18 40 lbs max shear 185 max comp
Grommet, 1.12 x .091-.125 nylon
Clip, Cable Retainer
Label, Disconnect Power, Multi-languages
Bushing Nylon 1-2" Nf810-5-0
Ring Retain 5-8" .579 Fr.Id
Foot, Rubber, Rear
Plate, Rear Rubber Foot Mount
Screw ,#10 x .5LG,T-S PLT, PNHD,TYB-B
Bolt Tap 1/2-13unc x 6 H x HD GR5
Bushing .50ID x .62OD x .31LG,flanged
Washer B 1-2 Narrow Zinc
Spring 1" O.D.360 Max Ld.
Rear Roller Hardware Assembly
Nut Holder Bracket
