Test Mode - CYBEX TROTTER Owner's Service Manual

! WARNING: All maintenance activities shall be performed by qualified personnel.
For any service related concerns, call Cybex
Customer Service at 800-766-3211 (for Cybex
customers living within the USA). For
customers living outside the USA, call 508-
533-4300 or fax 508-533-5183.
NOTE: Read and understand each procedure
thoroughly before servicing. Unless otherwise
noted "right" and "left" denote user orientation
for all procedures.

Test Mode

To enter Test Mode press and hold down any key on the display while turning the power
switch to the on (I) position. When all keys are released "Elite" and the software revision "rx.x" are
shown on the display. To exit Test Mode press Stop.
Stuck Key List
If Test Mode occurs without holding any keys, a key may be stuck closed or Error 7 may have
occurred. You may need to replace the upper and/or lower display overlay. See Figure 1.
If "KEY#" is displayed you can determine which key is stuck closed by referring to the
number list below.
Upper
Overlay
Lower
Overlay
Figure 1
1 Stop
2 Incline Down
3 Speed Down
4 Weight
5 Distance
7 Heart Rate
Service
Page 7-2
Cybex TROTTER Elite Treadmill Owner's & Service Manual
Failure to do so could result in serious injury.
1. select
program
heart rate
5K run custom 1
calorie goal 9 holes custom 2
Safety Sentry ™
stop
%
incline
8 Calorie Goal
9 Incline Up
10 Speed Up
11 Quick Start
12 Center Up
13 Custom 2
min
scan dist cal mets
mi / km
Cybex International, Inc. Medway, MA USA (508) 533-4300 www.eCybex.com Made in USA
time
e-stop
14 Level
15 Mets
16 5K
17 Enter
18 9 Holes
19 Center Down
2. adjust
time weight
enter
level age
wireless
heart rate
receiver
+
quick start
speed
-
20 Calories
21 HR Control
22 Time
23 Scan
24 Age
25 Pace
26 Custom 1
