Cybex TROTTER Elite Treadmill
Owner's & Service Manual
Cardiovascular Systems
Part Number LT-16601-4 Rev J
Cybex and the Cybex logo are registered trademarks of Cybex International, Inc. TROTTER and the TROTTER logo are registered
trademarks of Cybex International, Inc. Stableflex and the Stableflex logo are registered trademarks of Cybex International, Inc.
Safety Sentry™ is a registered trademark of Cybex international, Inc. Polar is a registered trademark of Polar.
DISCLAIMER:
Cybex International, Inc. makes no representations or warranties regarding the contents of this manual. We
reserve the right to revise this document at any time or to make changes to the product described within it without notice or
obligation to notify any person of such revisions or changes.
© 2003, Cybex International, Inc. All rights reserved. Printed in United States of America.
10 Trotter Drive Medway, MA 02053 • 800-766-3211 • 508-533-4300 • FAX 508-533-5183
www.eCybex.com • techhelp@cybexintl.com • techpubs@cybexintl.com • LT-16601-4 Rev J • April 2003
