Cybex TROTTER Elite Treadmill Owner's & Service Manual
3 - Operation
Read and understand all instructions and warnings prior to using the treadmill. See all of the
safety related information located in chapter 1.
Terms & Symbols Used
This section lists some of the common terms and symbols used in this chapter. Other terms
and symbols are listed in this chapter as appropriate.
Dormant Mode — This occurs when the treadmill is plugged in, turned to the on (I) position
and not in use. The control panel will display a beating heart when the treadmill is in Dormant
Mode.
Program Setup Mode — This begins after pressing any program key. Upon entering a
program the LEDs flash, prompting the user to adjust the appropriate settings.
Active Mode — This begins immediately after pressing the Quick Start key (Manual Mode),
or after the Program Setup Mode. The beginning of Active Mode is marked by the 3 second
countdown and running belt acceleration. Active Mode continues until you reach the end of a
program, disengage the
e-stop key or press the Stop key.
Quick Start — This begins by pressing the Quick Start key. Quick Start skips the Program
Setup Mode and begins immediately in Manual Mode.
Manual Mode — This begins immediately after pressing the Quick Start key. In Manual
Mode you can customize your workout Speed, Time and enter your Weight by pressing
those keys.
Workout Review — This begins in one of three ways: after pressing the Stop key once; at
the end of a program or when the treadmill detects that you are not there (see Safety Sentry
in this chapter). The workout statistics accumulated during the previous workout session will
display for 20 seconds (default setting) or until Stop is pressed again. NOTE: You can change
the 20 second default. See Setting Operation Options in chapter 5.
Pause Mode — This begins when the treadmill detects that you are not there and enters
Workout Review (see Safety Sentry in this chapter). While in Workout Review you can press the
Quick Start key to resume your workout. The time, calories burned and other accumulated
data is remembered and added to.
LM — These keys adjust Time, Level, Weight or Age up or down.
— These keys adjust Incline higher or lower.
+
+
— — These keys adjust Speed up (
) or down (—).
Operation
Page 3-1
