Set Mode - Icom IC-R6 Instruction Manual

D CI-V Address
To distinguish equipments, each CI-V transceiver/receiver
has its own Icom standard address in hexadecimal number.
The IC-R6's address is "7E."
When 2 or more IC-R6 receivers are connected with an op-
tional CT-17 - level converter, set a different address for
CI V
each of them in the range "01" to "DF."
D CI-V baud rate
Sets the baud rate. When "AUTO" is selected, the baud rate
is automatically set according to the connected controller or
other Icom CI-V radio. (default: AUTO)
D CI-V transceiver
CI-V transceive operation is possible even if the IC-R6 re-
ceiver is connected to an Icom CI-V radio. When set to "ON",
the frequency and the operating mode of the IC-R6 automat-
ically change to those of connected radios, and vice versa.
(default: ON)
(default: 7E)
