39
Mount the Intercom
If the thread on the conduit is longer than 3/8 inch, then a stop nut (not supplied) is required.
Otherwise, use the outlet box plug to plug the exit hole.
Figure A-2. Mounting the VoIP Intercom Assembly
HOLE PLUG
OR
CONDUIT
Figure A-3
shows the restrictions of the conduit going into the box.
Figure A-3. Conduit Restrictions
Not to Exceed 0.1"
CONDUIT (1/2")
Operations Guide
930242E
CyberData Corporation
