Table 2-2
Jumper
J1
J4
J3
JP2
JP4
JP5
JP6
JP8
JP11
Operations Guide
Figure 2-11. JP11—RTFM Switch Jumper
for the connector settings.
Table 2-2. Connector Settings
Setting
PoE Network Connection (RJ-45 ethernet)
J-Tag (Factory only)
Terminal Block (see
Call-Button/LED interface
Reset (Factory only)
Microphone Interface
Speaker Interface
Console (Factory only)
RTFM (see
930242F
Figure
2-7)
Section 2.1.6, "RTFM Switch
Installing the VoIP Intercom
Intercom Setup
Jumper")
