7. Enter the IP address of your TFTP server into the TFTP Server IP parameter field.
8. Enter the firmware filename of the file to be uploaded into the New Filename parameter field.
9. Click Upload File.
Note
Note
10. Repeat steps
Web Page Item
System Configuration
BootLoader
Firmware
TFTP Server IP
New Filename
Operations Guide
For example, kernel filename 201-image-spk-sip.bin.
This starts the upload process. Once the Intercom has uploaded the file, the Uploading
Firmware countdown page appears, indicating that the firmware is being written to flash.
The Intercom will automatically reboot when the upload is complete. When the countdown
finishes, the Firmware Upgrade page will refresh. The uploaded firmware filename should
be displayed in the system configuration (indicating successful upload and reboot).
If you are upgrading an older version of the Intercom firmware to version 3.3.0 or later,
several features will be in an unknown or random state. Therefore, in the case of a firmware
upgrade to version 3.3.0 or later, CyberData recommends that you go to the Intercom Setup
page and make sure the following values are set properly.
• Auto Answer
• Activate Relay on Ring
• Activate Relay on Button Press
• Relay on Button Press Timeout
• Button Lit when Idle
• Play Ringback Tone
On the Sensor Setup page make sure that all of the settings are set properly.
8 and 9 if you are uploading the Kernel and Application files.
For example, Application filename 201-romdisk-spk-sip.img.
Table 2-9 shows the web page items on the Firmware Upgrade page.
Table 2-9. Firmware Upgrade Parameters
Upgrade the Firmware and Reboot the Intercom
Description
Shows the current configuration.
Shows the current boot loader filename.
Shows the firmware for partition 1 and 2.
Enter the TFTP Server IP address.
Use this field to enter the new file name for the kernel or
application firmware file that you are uploading.
Click on this button to automatically upload the selected
firmware and reboot the system.
Link to the Network Setup page.
Link to the Intercom Setup page.
Link to go to the SIP Setup page.
