- Page 1 VoIP Intercom with 3CX Server Setup Guide CyberData Corporation • 2555 Garden Road • Monterey, CA • 93940 • T:831-373-2601 • F: 831-373-4193 www.CyberData.net...
-
Page 2: Setup Diagram
Intercom acts as a standalone SIP telephony device. Aastra 480i CT IP Phone xxx.xxx.x.xx NetGear EtherFast FS108P 10/100 8-port Pro-Safe Switch with PoE Server Setup Guide Figure 1-1. Setup Diagram 3CXSystem xxx.xxx.x.xxx (default) Windows Server 930272B CyberData VoIP Intercom xxx.xxx.x.xx CyberData Corporation... -
Page 3: Test Setup Equipment
2.0 Host PC Environment Description Hardware Type Windows Server Hardware Version Windows Server 2008 Software Type 3CX Phone System for Windows Software Version 6.1.0 3.0 Test Setup Equipment Equipment Aastra IP Phone Notes: CyberData VoIP Intercom Notes: Linksys EtherFast 10/100 8-port Workgroup Hub... -
Page 4: Setup Procedure
4.0 Setup Procedure To set up the 3CX SIP Server for the CyberData VoIP Intercom, 1. Go to the web address of the Login page. The web address is determined by the customer. 2. On the Login page, type the user name and password into the User Name and Password fields. - Page 5 3. Click on the Login button to go to the Main Page. 4. On the Main Page under the “Complete the following steps to start using 3cx Phone System for Windows:” section, look for the section that has the text, “Click here to add an extension.”...
- Page 6 Last Name 7. Click the Next button. You will see the Extension Created page. See Server Setup Guide (Figure 4-4), type the following information: Figure 4-4. Add Extension Page Email Address Password 930272B Next Login ID Figure 4-5. CyberData Corporation...
- Page 7 8. To register the Intercom, you will need to enter the information from the 3CX Extension Created page into the Intercom by logging into the CyberData Configuration Home page. Log into the CyberData Configuration Home page Intercom’s IP address. For the initial configuration of the Intercom, refer to the VoIP Intercom Operation Guide PDF which can be found at the VoIP Intercom product page at: http://www.cyberdata.net/support/voip/index.html...
- Page 8 9. When prompted, enter the following Web Access Username and Web Access Password to access the CyberData Configuration Home page (Figure 4-6): Default Login: Web Access Username: admin Web Access Password: admin Figure 4-6. CyberData Configuration Home Page 000000 SIP Config 10.
- Page 9 405 and configured to call extension 409. Save Settings 12. Click Save. Server Setup Guide is an example of a CyberData VoIP Intercom that is configured to extension Figure 4-7. SIP Config Page 930272B (Figure 4-5) to enter the following...
- Page 10 15. To test the Intercom, complete the following steps: • Pick up any phone that is configured to the 3CX system and call the Intercom’s extension number. • When a connection is established (as indicated by a beep), speak into the phone and verify that you can hear your voice through the Intercom.
-
Page 11: Frequently Asked Questions
5.0 Frequently Asked Questions Q: I upgraded my 3CX PBX server to 7.1 and now my Rev B CyberData VoIP Ceiling speaker and My VoIP Paging Amplifier do not stay registered with the server. A: There is a 3CX version 7.1 registration/timing bug. To correct this problem, complete the following steps: 1. - Page 12 2. Select Custom Parameters, and then scroll down to select a parameter called NONCEEXPIRATION. See Figure 5-2. Select Custom Parameters and then Select NONCEEXPIRATION 1. Select Custom Parameters 3. Change the NONCEEXPIRATION parameter value from 1 to 2 and save the changes. Figure CyberData Corporation Figure 5-2. 2. Select NONCEEXPIRATION 5-2. 930272B 3.
