CyberData 010935B Operation Manual page 30

2. On the Intercom Setup page, enter values for the parameters indicated in
Web Page Item
Device Name
Change Username
Change Password
Re-enter New Password
Speaker Volume (0 - 9)
Microphone Gain (0 - 9)
Auto Answer
Activate Relay During Ring
Activate Relay On Button Press
Relay on Button Press Timeout (in seconds) Type the desired number of seconds for the timeout on
Auxiliary Relay
DTMF Relay Activation Code (3 digits)
Relay Activation Duration (0 - 9 seconds)
Button Lit When Idle
Play Ringback tone
Operations Guide
Table 2-6. Intercom Setup Parameters
Description
Enter a descriptive name for this device (if desired).
Use this field to change the Web Access Username
Use this field to change the Web Access Password
Use this field to re-enter a new password
Shows the current volume level.
Shows the current microphone gain level.
When Auto Answer is Off, the Intercom will play a
ringtone through the speaker until someone presses the
button.
With the Activate Relay During Ring option, the relay
will be activated for as long as the phone is ringing.
NOTE: When the phone is set to Auto Answer, it will not
ring and this option does nothing.
If you select Yes, this will activate the relay for a user-
selectable amount of time when the button is pressed.
the relay after the button is pressed.
Allows you to enable or disable the auxiliary relay.
Use this field to enter the DTMF relay activation code.
Use this field to enter the relay activation duration.
If you select Yes, the front button light will remain on when
a call is not active.
If you select No, the front button light will remain off when
a call is not active. The button light will still flash when a
call is active.
If you select Yes, then while initiating a call to a remote
phone, this will enable the Intercom to play a ringtone
while the remote device is ringing.
Click on this button to save your configuration settings.
Click on this button to do a relay test. Generates a voice
message for testing the Intercom audio quality and
volume.
Click on this button to do an audio test. Generates a voice
message for testing the Intercom audio quality and
volume.
Link to the Home page.
Link to the Network Setup page.
930242F
Installing the VoIP Intercom
Configure the Intercom Parameters
Table 2-6.
CyberData Corporation
24
