4.3.1 RSSI LED Ranges
RSSI/Signal LED Status
On Solid
Fast Blink
Normal blink
Slow Blink
Extinguished
Activity - Lights will flash as data is transferred to and from the RLXIC-EH
modem on the remote network.
Power - Indicates the power adapter is connected, and there is power getting
to the RLXIC-EH.
The Reset button (on the left side of the RLXIC-EH) has two functions. If it is
quickly depressed and released, the modem will simply power cycle the
internal hardware. If, however, the reset is depressed and held for 45
seconds (count 45 slowly, and wait for the power light to go off after the light
pattern stops), the ALEOS configuration settings will return to the factory
defaults.
4.3.2 Light Patterns
The LEDs on the front of the modem will respond in different patterns to indicate
modem states.
Normal - Each LED, mentioned above, is lit as applicable.
Start up - The LEDs will cycle from left to right.
Configuration Reset - The LEDs will cycle left to right, and then right to left 4
times.
Authentication Failure - The Network, Signal, and Activity LEDs blink every
2 seconds.
Data Retry - The Network, Signal, and Activity LEDs blink every 3 seconds.
4.4

Mounting

An optional accessory for your RLXIC-EH is a DIN-rail mounting kit, which
includes a bracket. The bracket is designed to hold the modem in place on the
DIN-rail.
To install the radio in the mounting kit, follow these steps.
1 Mount the bracket using number 6 screws. There are two holes each, to
fasten screws, and minimum of one hole each end is required for mounting
bracket.
2 Position RLXIC-EH between Alignment ears.
3 Engage top groove in body of RLXIC-EH with two tabs.
4 Push on far side of RLXIC-EH in center so that it touches side of Bracket.
5 Press down and release when upper groove on far side of RLXIC-EH, aligns
with tabs.
6 Release to complete installation into mounting bracket.
Page 24 of 111
Hardware Installation of the RLXIC-EH
Ranges of RSSI (dBm)
Equal to or stronger than -69
-70 to -79
-80 to -89
-90 to -99
Equal to or weaker than -100
