Configuration Commands
User Manual
d.d.d.d=IP address or domain name
ppppp=the port address
Examples:
ATS53=T192.168.100.23/12345
ATS53=foo.earlink.com
Telnet to the specified IP at port 12345.
ATS53=192.168.100.23/12345
Query the specified IP at port 12345.
ATS53=/12345
Query port 12345.
Enable Event Reporting = n
Enable or disable Event Reporting, by selecting either 1-Turn on ER or 0-Turn off
ER. If you choose to enable, click on Write, and then Refresh all to see all the ER
fields.
n=0 : Disables
n=1 : Enables
+++
Note: +++ is not proceeded by AT nor does it require a carriage return (enter). There must be an
idle time (set by S50) on the serial port before and after this command.
AT Escape sequence. If the RLXIC-EH is in a data mode (any mode other than
PassThru), this command causes the modem to re-enter AT command mode.
The "+" is ASCII 0x2B.+++ is not available in AceManager.
Tip: DAE=1 disables the +++ command.
A/
Note: A/ is not proceeded by AT.
Re-execute last command. A/ is not used in AceManager.
A
Manually answer an incoming connection. A is not used in AceManager.
D[method][d.d.d.d][/ppppp] or D[method][@name][/ppppp]
Dial a connection to a remote IP and Port using method. Cannot be configured in
AceManager.
method=P : Establish a UDP connection
method=T : Establish a TCP connection
