Configuration Commands
User Manual
*NETWDOG=n
Network connection watchdog: The number of minutes to wait for a network
connection. If no connection is established within the set number of minutes, the
RLXIC-EH modem resets.
n=0 : Disabled.
n=minutes : Default = 120 min.
*SNMPPORT=n
This controls which port the SNMP Agent listens on.
n=0 : SNMP is disabled.
n=1-65535
*SNMPSECLVL=n
Selects the security level requirements for SNMP communications.
n=0 : No security required. SNMPv2c and SNMPv3 communications are
allowed.
n=1 : Authentication equivalent to "authNoPriv" setting in SNMPv3. SNMPv3
is required to do authentication, SNMPv2c transmissions will be silently
discarded.
n=2 : Authentication and encryption, equivalent to "authPriv" setting in
SNMPv3. SNMPv3 is required to do authentication and encryption, SNMPv2c
and SNMPv3 authNoPriv transmissions will be silently discarded. Messages
are both authenticated and encrypted to prevent a hacker from viewing its
contents.
*SNMPTRAPDEST=host/[port]
Controls destination for SNMP Trap messages. If port is 0 or host is empty, traps
are disabled. Traps are sent out according to the SNMP security level (that is, if
the security level is 2, traps will be authenticated and encrypted). Currently, the
only trap that can be generated is linkup.
host=IP address
port=TCP port
*SNMPCOMMUNITY=string
The SNMP Community String acts like a password to limit access to the
modem's SNMP data.
string =string of no more than 20 characters (default = public).
*TQUIT
Disconnects the telnet session. Not available in AceManager.
*RESETCFG
Wipe the non-volatile data in the modem. Cannot be used with AceManager.
