ProSoft Technology RLXIC-EH User Manual page 86

RLXIC-EH ♦ Intelligent Cellular
RadioLinx Intelligent Cellular Ethernet Gateway for HSUPA (3G GSM) Networks
Tip: Only letters, numbers, hyphens, and periods can be used in a domain name.
*IPMANAGERn=[name][IP address]
Sets a domain name or IP address to send IP change notifications to. Up to two
independent IP Manager servers can be set, using either AT*IPMANAGER1 or
AT*IPMANAGER2. Updates to a server can be disabled by setting that entry to
nothing (for example, "AT*IPMANAGER1=").
n=1 : First IP Manager server.
n=2 : Second IP Manager server.
name=domain name
*IPMGRUPDATEn=m
Sets the number of minutes to periodically send an IP update notification to the
corresponding server. This will occur even if the IP address of the RLXIC-EH
does not change. *IPMGRUPDATE1 is used to set the refresh rate to
*IPMANAGER1, while *IPMGRUPDATE2 is used with *IPMANAGER2. If the
value is set to 0, then periodic updates will not be issued (that is, IP change
notifications will only be sent when the IP actually changes).
n=1 : First IP Manager server.
n=2 : Second IP Manager server.
m=0, 5-255 : Number of minutes to send an update.
*IPMGRKEYn=key
Sets the 128-bit key to use to authenticate the IP update notifications. If the key's
value is all zeros, a default key will be used. If all the bytes in the key are set to
FF, then no key will be used (that is, the IP change notifications will not be
authenticated). AT*IPMGRKEY1 is used to set the key to use with
AT*IPMANAGER1, while AT*IPMGRKEY2 is used to the key with
AT*IPMANAGER2.
n=1 : First IP Manager server.
n=2 : Second IP Manager server.
key=128-bit key in hexadecimal [32 hex characters]
Page 86 of 111
Configuration Commands
User Manual
ProSoft Technology, Inc.
May 29, 2009
