Chapter 11: Specifications

Dock Dimensions

DIMENSION WITHOUT PRINTER
Width: 107 mm (4.2 inches)
Height: 84 mm (3.3 inches)
Depth: 109 mm (4.3 inches)
Weight: 570 grams (20 ounces)

Auxiliary Inputs/Outputs

Sensor: DB9
Data or
Power Input
Connector: Non-standard 16 pin docking connector for power and data.

Environmental

Operating Temperature
Oximeter and accessories: 0°C to 55°C (32°F to 131°F)
Power Supply: 0°C to 40°C (32°F to 104°F)
Li+ battery charging: 5°C to 45°C (41°F to 113°F)
Operating Humidity
Oximeter and accessories: 15 to 95% (non-condensing)
Power Supply: 5 to 95% (non-condensing)
Storage Temperature
Oximeter and accessories: -40°C to +75°C (-40°F to +167°F)
WW1090 LI-Ion rechargeable
Power Supply: -10°C to +70°C (14°F to 158°F)
Storage Humidity
Oximeter and accessories: 10 to 95% (non-condensing)
Power Supply: 5 to 95% (non-condensing)
Altitude:
Shock and vibration:
NOTE! The monitor may not meet performance specifications when stored or used outside
the temperature and humidity ranges listed above.
11-8
WITH PRINTER
160 mm (6.3 inches)
84 mm (3.3 inches)
109 mm (4.3 inches)
850 grams (30 ounces)
Printer: 0°C to 50°C (32°F to 122°F)
Printer: 20 to 85% (non-condensing)
battery pack: -20°C to +60°C (-4°F to 140°F)
Printer: -25°C to +70°C (-13°F to +158°F)
Printer: 10 to 90% (non-condensing)
3050 m (10,000 ft) max
ISO 9919 transport rated
