Turning On the Monitor

Press this key to turn
the monitor on and off.
To turn on the monitor, press the
up:
• All LEDs light.
• The monitor's software revisions (main, battery PIC, oximeter) are momentarily displayed.
• The patient record number is momentarily displayed.
After a few seconds the % SpO
be shown. If not, see Chapter 9: Troubleshooting for help.
WARNING! Verify that all LEDs (light emitting diodes) on the display light up upon startup
of the device.
If the oximeter detects an error during power up, "
the display. A numeric error code will display in the SpO
for more information.
Clinician's Operation Manual
Figure 4-6: Turning On the Monitor
x
key. Before using the monitor, check the following at power-
value, pulse rate, pulse signal strength and PI bar graphs should
2
ERR
Chapter 4: Operating Instructions
" will display in the pulse rate section of
section. See Chapter 9: Troubleshooting
2
4-7
