Serial Data Output; Power Input And Data Connector; Sensor Connector; Power Requirements - BCI WW1020 Operation Manual

Serial Data Output

Power Input and Data Connector

Data transferred through this connector is in a proprietary BCICP1030 format. Format available
upon request.

Sensor Connector

Data Type:
Serial Data Protocol:

Power Requirements

Battery

Type:
AA (LR6) disposable:
Custom rechargeable:
Use Time:
AA (LR6) disposable:
Custom rechargeable:
Charge Time:
AA (LR6) disposable:
Custom rechargeable:
Charge Cycles:
(Custom rechargeable)

AC Charger

WW1095 30 Watt AC Power Supply:

USB

WW1089 USB Interface Cable:
Length:

Monitor Dimensions

Width: 85 mm (3.3 inches)
Height: 154 mm (6.1 inches)
Depth: 45 mm (1.7 inches)
Weight: 340 grams (12 ounces) with four (4) AA batteries
369 grams (13 ounces) with rechargeable battery pack
Clinician's Operation Manual
ASCII comma delimited string output at 1 Hz. Lines terminated with a
carriage return.
RS232C, 9600 baud, 1 start bit, 8 data bits, 1 stop bit, no parity.
4 Alkaline
Lithium-Ion (L+), 7.4V replaceable rechargeable battery pack.
WW1020 - Approximately 26 hours continuous use
WW1000 - Approximately 32 hours continuous use
WW1020 - Approximately 31 hours continuous use (new)
WW1000 - Approximately 54 hours continuous use (new)
Not rechargeable.
Fast charges in approximately 3 hours. Charge time affected by input
power source and device loading. See Chapter 4: Operating Instructions.
300 to 80% capacity
9V, 3A output, Input of 100-240 VAC 50Hz, 60Hz.
Input: 5V, 500mA max (USB powered source )
Output: 9V, 230mA max to oximeter.
Maximum 5 meters (16.4 feet)
Chapter 11: Specifications
11-7
