Chapter 4: Operating Instructions
Unpacking the Monitor
The following items are shipped with the oximeter:
•
Monitor
•
Three (3) sensor cradles (WW1080)
•
Spot check sensor (3044S)
•
Four (4) "AA" (LR6) alkaline batteries
•
Operation manual
•
Service manual (CD)
Carefully remove the monitor and its accessories from the shipping carton. Save the packing
materials in case the monitor must be shipped or stored. Compare the packing list with the
supplies and equipment received.
Powering the Oximeter
The oximeter will operate from battery power or from external power with battery back up. The
optional WW1095 (30 Watt) AC power supply may be used to provide power to the oximeter. The
AC power supply is required when utilizing the docking station to ensure the proper operation
of the docking station with all accessories, including auxiliary battery charger and optional printer.
WARNING! The WW1020/WW1000 will not operate without batteries installed. Properly
charged batteries provide a reserve source of power in case of external power
failure. Never use an oximeter with discharged batteries to monitor a patient,
as the monitor may not operate properly in the case of external power failure.
The oximeter can obtain external power in the following ways:
•
The oximeter can be placed in its docking station. See
and Printer.
•
The AC power supply can be plugged directly into the oximeter (Figure 4-3).
•
The AC power supply can be plugged into the WW1089 USB Interface Cable (Figure 4-4).
•
The oximeter can be powered by a PC through the USB Interface cable (Figure 4-5).
Clinician's Operation Manual
Chapter 4: Operating Instructions
Chapter 6: Optional Docking Station
4-1
