Chapter 6: Optional Docking Station and Printer

Loading Paper

The printer uses 58mm wide thermal paper. See Chapter 10: Optional Supplies & Accessories for part
number and ordering information. To load the paper, follow the steps illustrated below.
1. Release printer door by lifting clear cover.
Figure 6-6B: Swing Open Paper Holder
4. Place paper spool in holder so that
the paper exits over the top of the
roll and drapes over the rubber
roller as shown in figure 6-6C.
Figure 6-6D: Close Paper Holder Door and Clear Cover
6-6
Lift here
Figure 6-6A: Release Printer Door
2. Swing open paper holder by
continuing to pull on clear door.
3. Remove existing spool if present.
Figure 6-6C: Place Paper Spool in Holder
5. Close the paper holder door and the clear
cover.
6. Tear off any excess paper by pulling the
paper up toward the front of the printer.
7. The printer is now ready to use.
