Chapter 11: Specifications

Displays

SpO :
2
Pulse Rate:
PI:
Pulse Signal Strength:
Display update rate
SpO and Pulse rate: 2Hz
2
All other data: 10Hz
Display Refresh:

Indicators

Visual
External Power indicator: (
Battery charge indicator: (

keys/User Controls

x
• On/Off Key ( )
Clinician's Operation Manual
2-digit LED display, 19 mm high.
3-digit LED display, 12.7 mm high.
9-segment LED bar graph.
Logarithmically scaled 9-segment LED bar graph.
50 Hz
green) with power plug icon.
green/yellow) with 4 segment gauge; green if 2-4 segments
lit, yellow if only one segment is lit.
