PROBLEM
No printout on AC power is not connected to
optional printer. the Docking Station.
No trends in memory.
No paper or paper incorrectly
loaded.
"?" malfunction Printer interface malfunction.
indicator on the
printer is lit.
Printer door open.
Printer out of paper.
Real time or An accessory cable is defective.
trend data is not
transmitted.
Oximeter is not properly seated
in Docking Station.
The communications setup is
not correct.
Display shows Remote alarm cable attached to
RA the oximeter.
ERR
Display shows No sensor attached to the
sr oximeter.
ERR
Defective sensor or patient
cable.
Display shows EEPROM checksum Error
24
ERR
Display shows Trend Checksum Error
25
ERR
Internal oximetry failure.
ERR
Display shows
Clinician's Operation Manual
POSSIBLE CAUSE
Chapter 9: Troubleshooting
CORRECTIVE ACTION
Connect AC Power to the Docking
Station.
Take trend data.
See Chapter 6: Optional Docking
Station and Printer for details of
loading paper.
Contact your authorized service
representative for help.
Close the printer door.
Install a roll of printer paper.
Contact your authorized service
representative.
Remove the oximeter from the
Docking Station and replace it
assuring proper alignment.
Check the user-connected auxiliary
equipment and software.
This is proper operation. The WW1020
and WW1000 are not intended for use
with the remote alarm cable.
Attach a sensor to the oximeter.
Try a new sensor. If the problem
persists, contact your authorized
service representative.
Contact your authorized service
representative.
Contact your authorized service
representative.
Contact your authorized service
representative.
9-3
