Output Format

Trend data is transmitted in the format shown in Figure 7-4.
1
2
3
1
Title
2 Patient Record Number
Newest data sample is printed first. Dashes mean no measurements
3
were available at that sample time.
4
Trended %SpO
2
Clinician's Operation Manual
TREND DATA
ID:009__________________
hh:mm:ss SpO2 Rate
(%)
00:55:08 --
00:55:04 95%
00:54:56 94%
00:54:52 96%
00:54:48 96%
00:54:44 96%
00:54:40 94%
00:54:36 96%
00:54:32 95%
00:54:28 96%
00:54:24 95%
00:54:00 --
Figure 7-4: Typical ASCII Trend Data Output
, pulse rate and PI values print every 4 seconds
Chapter 7: PC Communication Setup
PI
(bpm) (%)
--- --
83 bpm 1.6%
84 bpm 2.8%
83 bpm 2.6%
84 bpm 3.2%
84 bpm 3.6%
86 bpm 3.2%
86 bpm 3.2%
85 bpm 3.0%
85 bpm 3.0%
81 bpm 5.4%
--- --
