When placing the sensor on the patient, allow the cable to lay across the top of the hand and
parallel to the arm of the patient as shown in Figure 4-8.
Sensor (finger sensor shown for illustration only)
1
Cable
2
Clinician's Operation Manual
1
Figure 4-8: Positioning the Cable of the Finger Sensor
Chapter 4: Operating Instructions
2
4-13
