Rotate the Insight Display 90 degrees to view the display.
3.
Enclosure rear components
Item
1
2
3
4
5
6
7
8
Description
KVM module bay
Interconnect bay 1
Fan bays
("Fan bay
numbering" on page 87)
Interconnect bay 2
Enclosure link-down port
Enclosure link-up port
Onboard Administrator 1/iLO port
Onboard Administrator 2/iLO port (reserved for future
use)
Component identification 86
