Onboard Administrator components
Item
1
2
3
4
Onboard Administrator LEDs and buttons
Item
1
2
3
Description
Onboard Administrator bay 1
Onboard Administrator bay 2 (redundant, if used)
Enclosure link-up port
Enclosure link-down port
Description
Onboard Administrator UID LED
Enclosure UID LED and UID button
Onboard Administrator active LED
Component identification 80
