Accessing the Insight Display on the HP BladeSystem c7000 Enclosure
The Insight Display is located on the front of the HP BladeSystem c7000 Enclosure. The Insight Display slides
from side to side to allow access to enclosure components.
HP BladeSystem Insight Display components
Item Description
Insight Display screen
1
Left arrow button
2
Right arrow button
3
OK button
4
Down arrow button
5
Up arrow button
6
Function
Displays Main Menu error messages and instructions
Moves the menu or navigation bar selection left one position
Moves the menu or navigation bar selection right one position
Accepts the highlighted selection and navigates to the selected
menu
Moves the menu selection down one position
Moves the menu selection up one position
