Back-plane
Packet throughput
ability
LED
Network Cable
Power Supply
Power consumption
Install
Alarm
Operation Temp.
1.6 Gbps
2.38Mpps @64bytes (8TX)
Per port: Link/Activity (Green), Full duplex/Collision (Yellow)
Per unit: Power (Green)
Power 1 (Green)
Power 2 (Green)
Fault (Yellow)
Master (Green)
10Base-T: 2-pair UTP/STP Cat. 3, 4, 5 cable
EIA/TIA-568 100-ohm (100m)
100Base-TX: 2-pair UTP/STP Cat. 5 cable
EIA/TIA-568 100-ohm (100m)
12 ~48 VDC
Redundant power with polarity reverse protect function and
connective removable terminal block for master and slave
power
6.72 Watts
DIN rail kit and wall mount ears are provided for wall mount or
DIN-rail cabinet install
Provides one relay output for port breakdown, power failure
and provides DIP-switch to mask link down port.
Alarm Relay current carry ability: 1A @ DC24V
0 to 70 (32 to 158 )
