Comnet CWFE8MS/DIN Installation And Operation Manual page 41

Basic
1. Select
2. Management VLAN ID: this is used for Remote Management Security. It includes
remote management that includes telnet, SNMP, and Web browse the switch when
the port of the VLAN group ID is equal to the Management VLAN ID. Enter the
specific VLAN ID number in Management VLAN ID column and select the check box,
and select the
management VLAN ID is 101, the VLAN group ID 101 includes the port 1, 2, and 4.
Therefore, only port 1, 2, and 4 can remotely manage the switch. If the port is in two
different VLAN groups and one of VLAN group ID is equal to the assigned
Management VLAN ID, it still has the right to remotely manage the switch.
3. Group Name: Assign a name for the new VLAN
4. VLAN ID: Fill in a VLAN ID (2~ 4094). The default is 1
5. Select the ports from the ports list, and then, select
VLAN group
button
button to enable the function. For example: if the
35
to group the port as a
