Comnet CWFE8MS/DIN Installation And Operation Manual page 10

SNMP MIB
SNMP Trap
Class of service
Quality of service
X-Ring
VLAN
RFC 1213 MIBII
RFC 1493 Bridge MIB
RMON RFC 1757
RFC 2674 VLAN MIB
RFC 1643 Ethernet like MIB
RFC1215 Trap MIB
IGMP MIB.
Private MIB for switch information, X-Ring, port alarm, TFTP
firmware upgrade, reset, port mirror, IP security
Up to 3 Trap stations
Cold start, Port link Up, Port link down, Authentication Failure
Private Trap for power status
Port Alarm configuration
Fault alarm, X-Ring
IEEE802.1p class of service support
Per port provides 4 priority queues
The quality of service support port based
Tag based and IPv4 Type of service
2 ports for X-Ring to provide redundant backup feature and
the recovery time below 300ms. It also supports coupling ring
function. Ring and coupling port configure by web interface
and ringmaster by hardware DIP switch
Port based VLAN
IEEE802.1Q Tag VLAN
Both of port based and Tag based VLAN group up to 64
VLANs
4
