5.14.2 Per Port Configuration

Configuring the path cost and priority of every port
1. Select the port in Port column
2. Path Cost: The cost of the path to the other bridge from this transmitting bridge at the
specified port. Enter a number 1 through 200000000.
3. Priority: Decide which port should be blocked by priority in the LAN. Enter a number
0 through 240. The value of priority must be the multiple of 16.
4. Admin P2P: Some of the rapid state transactions that are possible within RSTP are
dependent upon whether the port concerned can only be connected to exactly one
other bridge (i.e. it is served by a point-to-point LAN segment), or can be connected
to two or more bridges (i.e. it is served by a shared-medium LAN segment). This
function allows the P2P status of the link to be manipulated administratively. True is
P2P enabled. False is P2P disabled.
5. Admin Edge: The port directly connected to end stations cannot create a bridging
loop in the network. To configure the port as an edge port, set the port to "True"
status.
6. Admin Non STP: The port includes the STP mathematic calculation. True does not
include STP mathematic calculation. False does include the STP mathematic
calculation.
7. Select
[NOTE] Remember to use "Save Configuration", otherwise the new configuration will be
lost when the switch is powered off.
button
48
