Reset Button
The reset button provides the user with an easy way to restart and reset the
configuration back to default value.
Restart: press the button for 2 seconds and release.
Set to factory default value: press the button for 5 seconds and release. The
switch will set all configurations back to the original default settings.
2.3 Bottom View
The bottom panel of the CWFE8MS/DIN managed Ethernet switch consists of one
terminal block connector within two DC power inputs and one DC IN power jack.
Bottom Panel of the industrial switch
8
