User List; Figure 14- User List - NTI RACKMUX-T15-CS16/8 Installation And Operation Maintenance

NTI RACK MOUNT CONSOLE TERMINAL WITH CONSOLE SWITCH

3.1.4 User List

From the administrator main menu, press [4] to display the User list.
Column Heading Description
User User Index number
User Name User name associated with the index number
En User status- "Y" = enabled " -" = not enabled
Adm Displays if user has administrative rights "Y" = yes "-" = no
Port access Displays what ports the user has access to
Log Identifies what port the user is logged into, if any
Con Identifies what port the user is connected to (Pxx)
Or if the user is logged in as an administrator (Adm)
Or if the user is just logged in (Usr)
Press [R] to refresh the information and repaint the screen.
-
- Press [N] to see the next page; press [P] to see the first page.
- Press [Esc] or [Space] to return to the "Administrator main menu".

Figure 14- User List
