NTI RACK MOUNT CONSOLE TERMINAL WITH CONSOLE SWITCH
Verbose mode
Send or type in:
[V] [Enter]
The answer will be:
OK [CR][LF]
and the Terse mode will be terminated. The "Accessible host list" or the "User main menu" will be displayed.
User Logout
Send or type in:
[L] [Enter]
The answer will be:
OK [CR][LF]
With the next login of the same user, Terse mode will resume.

3.2.5 System Reset button

The "System Reset" button, located on the rear of the RACKMUX (see Fig. 24), may be pressed at any time to refresh the
SERIMUX without powering it OFF. This might be necessary in the event the SERIMUX should fail to respond to normal
commands.

3.2.6 Restore SERIMUX Console Switch to default settings

SERIMUX can be restored to default settings by using the "Restore Defaults" button
The RACKMUX should be OFF before pressing the "Restore Defaults" button.
1. Press and hold the "Restore Defaults" button using a small object that will fit through the hole in the back of the SERIMUX.
(See Fig. 21).
2. Turn ON the RACKMUX.
3. Wait 3 seconds.
4. Release the button.
SERIAL
16 15 14 13
Caution: During initialization, the customer modified parameter values will be replaced with the factory default values
(for default values, see Table 2, page 31), user names and passwords will be erased.
System Reset button
PRINTER PARALLEL
TERMINAL
10 BASE T
11
12 10 9 8 7 6
Rear View of RACKMUX

Figure 24- Location of Restore Defaults button

Restore Defaults button
RESTORE
SYSTEM
DEFAULTS
RESET
5 4 3 2 1
30
